Setting Up NetScout Manager Plus for FrameSaver Devices
8-7
9124-A2-LB20-00
March 2000
3. To add a FrameSaver SLV-supported domain or correct property settings,
select the Edit... button (to the right of the Domain section of the Property
Editor window). The Edit Domain window opens.
4. Click on the domain from the Domains list and configure the following:
Property
Description Setting
Groups
Stats (S) Statistics collection Enabled for all domains.
Hosts (H) Level 3 information
(network)
Enabled for IP domain only.
Disabled for all other
domains.
Conversations (C) Protocols being used Disabled for all domains.
Logging Event logging Disabled for all domains and
groups.
5. Select the OK button (at the bottom of the screen) to apply the changes.
Refer to Configuring Domains in Properties Files in the NetScout Manager/Plus &
NetScout Server Administrator Guide for additional information.
